Equipment introduction
The 10-level universal battery sorting machine is a device for testing and sorting cylindrical batteries based on parameters such as internal resistance and voltage. It features a built-in high-precision automatic internal resistance and voltage testing system. The machine accurately places batteries into designated levels based on the internal resistance and voltage values set on the human-machine interface software. The system can achieve up to 10 levels (9+1, 9 OK levels and 1 NG level). It boasts a simple and elegant design and stable performance. Currently, it is one of the most cost-effective sorting machines on the market.
Equipment advantages
| Operating voltage | phaseAC220V±59%/50Hz,Powe:Ps600W | Sorting machine frame material | quality thick cold rolled shest and 40×40square tube |
| working air source | 0.4~0.6Mpa | Electronic control devices |
PLC, stepper motor control, branded sensors and other accessories. |
| Adapted to battery specifications |
21700 eylindricalcell |
User interface | touchscreen |
| efficiency | ≥3000~3500 | instrument | Standard configuration includes HK3561 (brand and model can be selected according to customer requirements). |
| The silo has approximately [amount missing] of material. |
21700=350 battries |
Sorting parameters | OVC.AC internal resistance |
| Equipment weight | about 300kg | Open circuit voltage | OVC prcision+-0.10%rdg,display rosolution ratio 0.1m |
| External dimensions | 1390(L)×840(W)×1405(H)mm |
